ePropulsion I-10

Specifications

Model	I-10	Category Name	Inboard Engines	Year	2025
Sale Type	New	Manufacturer	ePropulsion	Odometer	km
Weight	45kg	Input Power	10 kW	Input Voltage	86 to 115 VDC
Cooling System	Air cooling	Connectivity Service	Support	Dimensions (L X W X H)	565 x 295 x 380 mm
Rated Rotational Speed	1500 rpm	Operation And Interaction	Throttle & display (standard)	Price	Contact for price CAD

Description

Electrification of KSSS Pass Boat Häftig Featuring ePropulsion I-20 Inboard & G Batteries

ePropulsion converted the KSSS pass boat Häftig, known as Baljan, into an electric vessel with twin I-20 inboards, 4 x G102 batteries, and a 15 kW charger for transporting guests in the Stockholm archipelago. Operating a fixed route of over 1 NM between three piers, Baljan runs one trip per hour. In its first season, the boat achieved 273 hours of operation, covered over 600 NM, and saved 900 liters of diesel, reducing CO2 emissions by approximately 2.4 tons.

Bring Sustainable Solutions to the Waterways of France

ePropulsion has collaborated with the French boat rental company Les Canalous to create its first fully electric canal boat, enhancing their fleet and commitment to sustainability. The upgraded Lapeniche-s is a six-cabin hybrid vessel for up to 12 guests, powered by ePropulsion’s I-20 inboard motor, a 5” digital display, remote smart throttle, and four G102-100 batteries. With an onboard generator powered by HVO fuels, the boat can operate independently of charging stations, significantly reducing greenhouse gas emissions by up to 90%.

FEATURES

Compact and Integrated

A compact design that integrates five functional modules of motor, gearbox, motor controller, system control unit and cooling system into a very small space.

Space-saving

Take up 60% less space than typical combustion engines and greatly reduce the machine size*, providing installation flexibility and maximizing payload space for you.

Lighter weight

65% less weight than typical combustion engines and 30% lighter than electric inboard motors of similar range.

Easy to install

Internal wiring has been connected before delivery, providing you with an out-of-the-box experience.

Easy to maintain

The technology and the design of the interfaces significantly lower the maintenance required than combustion engines.

Build on
the state-of-art eSSA

Underpinned by the ePropulsion Smart System Architecture (eSSA), the I-Series inboard motor gives you a state-of-art solution. It features a smart and modular design to deliver you with safe and reliable performance and also supports the integration of ePropulsion Connectivity Service and ADAS.

New Generation Controls under eSSA

The Smart Throttle and Smart Display 5″ provide excellent user experience in controlling and monitoring. The Smart Throttle supports 3 mounting options for flexible installation. You could always find a best fit for your boat.

Top or Side
Single or Dual
Portside or Starboard

Integrated with boating IoT

ePropulsion Connectivity Service is a value-added service enabling boat owners and fleet managers to communicate with their boats securely and reliably. It allows users to access cloud-based connectivity services without the need for additional accessories.

Remote data access
You can check all real-time data, such as location, speed, battery level, remaining charging time, etc.

Remote monitoring
Notify users when boats break geofences, exceed speed limits and have suspicious location changes.

Trip tracking
Automatically create boating trips with route playback and trip log.

Shared accounts
Invite other people to share access to real-time status, past activities and reports.

Guest authorization
Remotely authorize guests to power on and operate ePropulsion system with limited permissions.

Report generation
Automatically create boat reports and fleet reports to summarise all boating activities.

BATTERY

The G102-100 battery is designed to be fully compatible with your 96V 10kW to 40kW I-Series inboards.

Fully Compatible with I-Series Inboards
Safe and Reliable
High Energy Density
Long Life Cycle

LITERATURE

Name	Link
User Manual：1-10	Downlowd
Technical Drawing：1-10	Downlowd
